NUFLO Camcor CT Series Coriolis flow meter

Overview

Specifications

NUFLO CamCor CT Series

  • Deep U-shaped dual sensors maximize accuracy
  • Flow rate turndown up to 200:1
  • Low-temperature models suitable for cryogenic fluids, such as LNG, down to -328 ̊F (-200 ̊C)
  • High-temperature models suitable for temperatures up to +662 ̊ F (+350 ̊ C)
  • Suitable for liquids and gases
  • Sensor sizes from <1mm through 10”
  • Ability to measure rates from 0-0.032 GPH to 0-423,000 BPD
  • Flow rate uncertainty on liquids +/-0.1% (+/-zero stability error)
  • Density uncertainty +/-0.0005 g/ml (CC003 through CC250)
  • Wetted materials are 316/316L SST or Alloy C22
  • OIML R117 metrology qualification
  • Global hazardous location certifications
  • CRN/ASME B31.3 pressure code

Both series also feature:
  • Transmitter features available as integral or remote-mounted
  • Extensive I/O count, including dual independent pulse outputs, dual independent analog outputs, status input, and status output
  • Communications: Modbus* RS-485 and HART* compliant
  • Easy access to details and functions by through-the-glass keypad or PC interface
  • Diagnostic check for pipeline vibration and media pulsation

Product resources

Manuals & Support

NUFLO CamCor Coriolis flowmeters Manual

Manual

NUFLO CamCor Coriolis flowmeters Modbus Protocol Manual

Manual

NUFLO CamCor CT custody-transfer Coriolis flowmeters Technical Specifications User Guide

Manual

NUFLO CamCor EZ-Link user interface software Manual

Manual

Marketing collateral

NUFLO CamCor Coriolis flowmeters Product Sheet

Product datasheet

Software

EZ-Link Service Edition - CamCor Coriolis – V3.3.0SE

Software

EZ-Link Standard Edition - CamCor Coriolis – V3.3.0E

Software
